FL WLAN 1100/1101/2100/2101
8
PHOENIX CONTACT 107390_en_03
1.1.1 Product variants
1.2 Country approvals for FL WLAN 110x/210x
1.2.1 FL WLAN 1100/2100
The FL WLAN 1100/2100 is a WLAN device with access point and client functionality. The
device uses the WLAN standard in the license-free 2.4 GHz and 5 GHz bands, which are
free of charge.
The device satisfies all the requirements of Directive 2014/53/EU:
– Additional information can be found in the manuf
acturer's declaration, which is avail-
able in the e-shop at phoenixcontact.net/product/2702534
.
Depending on the maximum possible transmission power, device operation must be ap-
proved or registered in some countries. Furthermore, there may be a usage restriction for
the transmission power.
Approvals for other countries are available on request.
Phoenix Contact hereby declares that this wireless system complies with the basic require-
ments and other relevant regulations specified in Directive 2014/53/EU. The EU declaration
of conformity can be found in the "Download" area via the following link: phoenixcon-
tact.net/product/2702534.
Table 1-1 Product variants
Device Properties
FL WLAN 1100
2702534
– Protection class IP54 (when mounted on a level surface, such as
control box or similar)
– Temperature range 0°C…60°C
– Approval for Europe and other countries
FL WLAN 1101
2
702538
– Like FL WLAN 1100, with approval only for USA / Canada
FL WLAN 2100
2
702535
– Protection class IP65/66/67/68 (when mounted on a level surface,
such as control box or similar)
– Temperature range -40°C…60°C
– Approval for Europe and other countries
FL WLAN 2101
2
702540
– Like FL WLAN 2100, with approval only for USA / Canada
A current list including the national approvals is available in the e-shop at
phoenixcontact.net/product/2702534
.
Make sure you observe the regulations of the relevant regulatory body for device opera-
tion in all countries.
