Page #124 background imageLoading...
Page #124 background image
Application manual for PSRclassic and PSRmultifunction, and the modular safety relay system
124 / 136
PHOENIX CONTACT 102597_en_03
The table is valid for the following safety relays:
1 PSR-ESD/5x1/1x2/300
2 PSR-ESD/5x1/1x2/T
Table 8-3 Diagnostic description for PSR-ESD/5x1/1x2/… safety relay
PWR
K1
K2
K3(t)
K4(t)
Fault Remedy Valid for
Connection/
voltage error
Supply voltage not present. Apply supply voltage.
All
Supply voltage too low. Adjust supply voltage.

The enable circuits are connected
incorrectly or not connected at all.
Check the connection of the
enable circuits.
No bridge between Y1 and Y2. Insert bridge.

Missing bridge between S10 and S11.
E.g., for two-channel emergency stop
wiring.
Insert bridge.
Cross-circuit

Between both enable circuits
S10/S11-S12 and S21-S22.
E.g., for emergency stop or safety
door.
Remove cross-circuit.

Between both enable circuits S10 and
S12.
E.g., for light grid type 4.
Short circuit
Between contact points A1 and A2.
Remove short circuit.

Between S11 and S12.
Fault detection on next demand.

Between S21 and S22.
Fault detection on next demand.
Fault in
reset circuit

Faulty reset button.
Short circuit between S33 and S34.
No fault detection on initial start, only
on first new demand.
Remove short circuit.
Fault with
internal cause
Enable contact(s) of K1 faulty. Replace safety relays. All
