3.2 Maximum cable lengths
Depending on the size of the machine or system, a considerable amount of cabling may be
required to wire the sensors.
Figure 3-2 Example for calculating the cable lengths
Make sure that the specified cable lengths are not exceeded, so as to ensure error-free
operation of the safety relay.
L+
(L1)
M
(N)
R1 R2
R3
PSR-ESAM4
A1 S11 S12 S21 S22
13 23
A2 S34 S35
14 24
41
42
(+)
()
(GND)
()
()
()
33
34
