PHOENIX DIGITAL OCM-DPR-1 - Rockwell Allen-Bradley Dh+;Rio 1756 Plug-In

DH+/RIO OPTICAL COMMUNICATION MODULES USERS MANUAL
Copyright © 2003 by Phoenix Digital Corporation, All Rights Reserved.
1-12
A
B
Ch A Ch B
ACT/ERR ACT/ERR
Ch A Ch B
ISD/IFD ISD/IFD
LOCAL OK
Tx/Rx
ROCKWELL ALLEN-BRADLEY DH+/RIO
1756 PLUG-IN OCX CONNECTOR DESIGNATIONS
FIGURE 6
Ch A Tx
Ch A Rx
Ch B Tx
Ch B Rx
ISS
ISS
TM
FIBER OPTICS
RSS
(Analog Outputs)
DH+/RIO TWINAX
HARDWIRE CONNECTION
ON BOTTOM OF MODULE
J1 CONNECTOR (UNUSED)
J2 CONNECTOR
1
2
3
