PHOENIX DIGITAL OCM-DPR-1 - 1771 Plug-In Ocm and 1746 Plug-In Olc; Diagnostic Status and Control

DH+/RIO OPTICAL COMMUNICATION MODULES USERS MANUAL
Copyright © 2003 by Phoenix Digital Corporation, All Rights Reserved.
READ STATUS BYTE
0 = NORMAL (INACTIVE)
1 = ASSERT (ACTIVE)
MODULE RESET (VERIFY)
TRAP MODE SELECT (VERIFY)
CH-B ERROR FORCED (VERIFY)
CH-A ERROR FORCED (VERIFY)
CH-B IMPENDING FAULT DETECT
CH-B ERROR
CH-A IMPENDING FAULT DETECT
CH-A ERROR
WRITE CONTROL BYTE
BIT76543210
0 = NORMAL (INACTIVE)
1 = ASSERT (ACTIVE)
TRAP MODE RESET
TRAP MODE SELECT
FORCE CH-B ERROR
FORCE CH-A ERROR
UNUSED
IMPENDING FAULT DETECT ENABLE
UNUSED
UNUSED
1771 PLUG-IN OCM AND 1746 PLUG-IN OLC
DIAGNOSTIC STATUS AND CONTROL FUNCTIONS
FIGURE 9
BIT76543210
1-27
