DH+/RIO OPTICAL COMMUNICATION MODULES USERS MANUAL
Copyright © 2003 by Phoenix Digital Corporation, All Rights Reserved.
OPTICAL TRANSMITTER (1300nm MULTIMODE)
Electro-Optical Characteristics
Parameter Test Condition SYM. MIN. TYP. MAX. UNITS
Fiber 50/125 micron Poc 25/-16.0 microwatts/dBm
Coupled Graded, 0.20NA
Power 62.5/125 micron 50/-13.0 microwatts/dBm
Graded, 0.28NA
Wavelength λ
P
1290 1350 nm
Spectral λ
W
160 nm
Width
OPTICAL TRANSMITTER (1550nm MULTIMODE)
Electro-Optical Characteristics
Parameter Test Condition SYM. MIN. TYP. MAX. UNITS
Fiber 50/125 micron Poc 50/-13.0 microwatts/dBm
Coupled Graded, 0.20NA
Power
Wavelength λ
P
1510 1580 nm
Spectral λ
W
45 100 nm
Width
TABLE 6
TABLE 5
1-16
