PHOENIX DIGITAL OCM-DPR-1 - Page 53

DH+/RIO OPTICAL COMMUNICATION MODULES USERS MANUAL
Copyright © 2003 by Phoenix Digital Corporation, All Rights Reserved.
(1) See Figure 8 for designated switch locations
(2) ON = Enable (Active, Switch Closed)
OFF = Disable (Switch Open)
(3) See Tables 18 and 19 for details on Network Key-Up Selection
(4) All unused switch positions must remain set in the Factory Default
Configuration.
(5) See Table 17 for details on Network Baud Rate Selection.
STANDALONE, PANELMOUNT AND 1771 PLUG-IN OCM MODULE
CONFIGURATION SWITCH DEFINITIONS
TABLE 16
FACTORY
SWITCH
(1)
POSITION
(1)
FUNCTION
(2)
CONFIGURATION
(DEFAULT)
Switch 5 1 Network Key-Up Select
(3)
ON
(SW 5) 2 Network Key-Up Select
(3)
OFF
3 Unused
(4)
OFF
4 Unused OFF
5 Baud Rate Select
(5)
OFF
6 Baud Rate Select
(5)
ON
7 Network Key-Up Select
(3)
ON
8 Network Key-Up Select
(3)
OFF
9 Network Key-Up Select
(3)
OFF
10 Unused OFF
