USEPHOENIX.COM | 800-533-7533
12
R250| LGR Dehumidifier Installation, Operation, and Maintenance Instructions
5.4 CONDENSATE PUMP
The internal condensate pump removes water that collects in the reservoir.
To replace the condensate pump:
1. Unplug the unit
2. Remove the front housing
3. Unplug the pump wires from the wire harness
4. Remove the condensate hose and the two nuts attaching the pump to the
bracket
5. Replace the pump, hose, wiring, bolts, and housing in the reverse order
5.5 FLOAT SAFETY SWITCH
The float safety switch activates when the water rises too high in the condensate
reservoir. The float safety switch turns off the compressor until the water level lowers
and disengages the switch.
To replace the float safety switch
1. Unplug the dehumidifier
2. Remove the front housing
3. Unplug the float safety switch wires from the wire harness
4. Slide out the float switch from under the compressor support
5. Remove the one screw attaching the float switch bracket to the compressor
support
6. Replace the float, pump, wiring, bolts and housing in the reverse order
6 OPTIONS & ACCESSORIES
4025568 Air Filter, Pleated 12” x 12” x 1” MERV-11
4024750 Inlet Flex Duct 12” x 25” Metallize Polyester
4024935 Lay-Flat Duct 10” Round x 250’ Roll
4026309-02 10” Duct Ring
To order, contact your local distributor.
