Unifarm Machinery Corporation
PO Box 38, Wilson, NC, U.S.A.
page 18
Before replacing the blades, turn the tractor engine off, pull
the parking brake, disengage the power take off, raise the
tiller using the tractor lift, and install supports to prevent
accidental dropping of the machine.
Pay special attention to the bolts A on the blades (picture 15): the screw head must be placed on
the blade side, with the washer and the nut on the flange side, so that the bolts cannot loosen while
the equipment is being used.
When several blades must be replaced, replace one blade at a time, so that the initial helical layout
is maintained (picture 16).
picture 15 picture 16
HOW TO ORDER SPARE PARTS
For spare parts requests please refer to the spare parts catalog.
The spare parts can be ordered from the dealer or service center. The following data must always be
specified:
- Equipment type and width.
- Part number of the requested component. If the code number is missing, indicate the table
number in which it is shown and the relevant reference.
- Description of the part and requested quantity.
- Requested type of transport. Should this information not be provided, the dealer or service
center shall not be responsible for delays caused by circumstances beyond their control. The
addressee shall be responsible for any transport charges.
