OnWave system setup and operation (cont’d)
8
2b
remote-mount a
standard antenna
optimizes transmitter/antenna position
2c
remote-mount a
large-area antenna
optimizes transmitter/antenna position
then
then
100m
300ft
300m
1000ft
>2m/6ft
PE 560T
ground plane with
cable (AT0776)
or
ground plane with
connector kit
(AT0775)
PE 560T
PE 560T
AT0773 Channels
A–E, 1–20
or
AT0774 Channels
F–J, 21– 40
PE 560T
or
NOTE:
! Ground mounting pole or
holder.
! Ground antenna if outdoors.
! Do not install near power
cables or service drops.
! Do not install parallel to metal
structure within 2m/6ft
(perpendicular to metal ok)
AT0776
AT0775
