Phonic Ear OnWave - Connect Microphone Input; Activate Phantom Power

OnWave system setup and operation (cont’d)
10
4b
connect microphone input
then
PE 560T
XLR input
2mV
rms
4c
activate phantom power
(for electret condenser mics only
†
)
Repeat steps to deactivate
phantom power
†Use phantom power only
with condenser microphones.
Plugging dynamic mic in
while phantom power is
activated may damage
the microphone
Plug in microphone
Select Mic-in
Press function
Press line/mic
2
1
2
1
2
1
2
1
3839 OnWave User Guide 1/15/04 11:40 AM Page 24
