AM642D / AM642DP / AM642D USB
English
SPECIFICATIONS
AM642D AM642DP AM642D USB
Inputs
Total Channels 10 10 10
Balanced Mono Mic / Line
channel
6 6 6
Balanced Stereo Line
Channel
4 4 4
Aux Return 2 stereo 2 stereo 2 stereo
2T Input Stereo RCA Stereo RCA Stereo RCA
Outputs
Main L/R Stereo 2 x 1/4” TRS, Bal. & 2 x XLR 2 x 1/4” TRS, Bal. & 2 x XLR 2 x 1/4” TRS, Bal. & 2 x XLR
Rec Out Stereo RCA Stereo RCA Stereo RCA
CTRL RM L/R 2 x 1/4” TS 2 x 1/4” TS 2 x 1/4” TS
Phones 1 1 1
Channel Strips 10 10 10
Aux Sends 3 3 3
Pan/Balance Control Yes Yes Yes
Channel insert CH 1~ CH 6 CH 1~ CH 6 CH 1~ CH 6
Volume Controls 60mm fader 60mm fader 60mm fader
Master Section
Aux Send Masters 3 3 3
Master Aux Send Solo 3 3 3
Stereo Aux Returns 2 2 2
Aux Return Assign to
Subgroup
1 1 1
Effects Return to Monitor 2 2 2
Global AFL/PFL Solo Mode Yes Yes Yes
Phones Level Control Yes Yes Yes
Faders
Aux return 2, Aux 1, 2
subgroups, Main L & R
Aux return 2, Aux 1, 2
subgroups, Main L & R
Aux return 2, Aux 1, 2
subgroups, Main L & R
Metering
Number of Channels 2 2 2
Segments 12 12 12
Phantom Power Supply +48V DC +48V DC +48V DC
Switches Master Master Master
32/40-bit Digital Effect
Processor
16 effects 16 effects 16 effects
Built-in Graphic EQ Stereo 9-band Stereo 9-band Stereo 9-band
Center Frequency
60, 160, 315, 630, 1.25K,
2.5K, 5K, 10K, 16K Hz
60, 160, 315, 630, 1.25K,
2.5K, 5K, 10K, 16K Hz
60, 160, 315, 630, 1.25K,
2.5K, 5K, 10K, 16K Hz
Range ±12 dB ±12 dB ±12 dB
USB Player
Maximum Playback Bitrate - 320 kbit/second -
Supported Playback
Formats
- WAV, WMA and MP3 -
