Phonic DFX256 - Sample Connections; Connection Diagrams

15
DFX256
SAMPLE CONNECTIONS
ONE MONO CORD IN, ONE MONO CORD OUT (to an amplification system or mixer input)
ONE MONO
CORD IN, TWO MONO CORDS OUT (to a stereo amplifier or two mixer inputs)
TWO MONO CORDS IN AND OUT (to a stereo amplifier or two mixer inputs)
This
can be stereo signal in/out or mono signal in/out.
INSTRUMENT
OF
EFFECTS SEND
TO MIXING CONSOLE OR AMPLIFIER
INSTRUMENT OF
EFFECTS SEND
TO MIXING CONSOLE OR AMPLIFIER
INSTRUMENT
OF
EFFECTS SEND
TO
MIXING CONSOLE OR AMPLIFIER
SAMPLE CONNECTIONS
