SPECIFICATIONS
Audio Inputs
Main In HF-ltered, servo-balanced XLR and 1/4" TRS connectors
Input Impedance 0k ohm balanced, 40k ohm unbalanced
Sensitivity -34dB
Max. Input Level +16 dBu at +4dBi nominal level, +1 dBV at -10 dBV nominal level
CMRR typically 40dB, >55 dB@1kHz
AUX In 1/4"TRS connector (stereo)
Input Impedance 5k ohm
Sensitivity -20dB
Max. Input Level +22 dBu
Direct In 1/4"TRS connector (stereo)
Input Impedance 15k ohm
Sensitivity -28dB
Max. Input Level +22 dBu
Audio Outputs
Main Output XLR and 1/4"TRS connectors, balanced
Phones Output 1/4"TRS connector (stereo)
Power Amplier
Max. Main Output Power +22 dBm (load impedance 8 ohm)
Max. Phone Output Power
+19 dBm (load impedance 100 ohm)
+7 dBm (load impedance 8 ohm)
Min. Output load impedance 8 ohm
System Specications
Frequency response 10Hz to 150kHz, +/-3dB
Noise 22Hz to 22kHz>90dB@0dBu
Dynamic range 22Hz to 22kHz:110 dB
THD 0.006% typ.@+4dBu, 1 kHz, gain1
Function Control
Input level Variable
Balance per channel
mix between Aux and Main signals/balance
between right and left channel
Out level per channel Variable
Treble cutoff frequancy 12 kHz; range +/- 12 dB
Bass cutoff frequancy 80 Hz; range +/- 12 dB
Function Swtiches
Stereo/2-Channel swtiches between stereo mode and 2-ch mode
Left mute mutes the left signal of the respecitve channel
Right mute mutes the right singal of the respective channel
Display
Input Level 4-digit LED-Display: -30/-10/0 dB/clip
Output level 4-digit LED-Display: -30/-10/0 dB/clip
Power Supply
Mains voltage
USA/Canada 120V~, 60Hz
Europe/U.K/Australia 230~, 50Hz
Japan 100V~, 50-60Hz
gerenal export model 120/230 V~, 0-60Hz
Power consumption 34W
Dimensions 483 x 44 x 206 mm (19" x 1.7" x 8.1")
Net Weight 2.22 kg (4.9 lbs)
