Phonic POWERPOD1860 - Channel 1-8 Schematic; Channel 1-4 Schematic

V- V+
V+ V-
V- V+
V+ DG
V+ DG
DG
V+
V+48V
GAIN ====
LINE INS
TIP RING RING TIP
FADER =====
MONI 2 MONI 1 ====== ======
PAN ===
33
2
2
22
11
1
1
3
1
2
3 4
5
6
PFL ===
LOW HIGH
PEAK ====
3
3
1
1
2
+
3
3 1
2
MUTE ===
1
2
3 4
5
6
====== EFFECT3 2
1
+
LOW CUT =======
1 3
2
4 6
5
===
===
====
2
+
+
RESISTORS ARE SMD TYPE UNLESS MARKED.
G1 G2
NOTE:
13
2
MID
===
C101A;LOW LEAKGE ELECTROLYTIC CAPACITORS
3
+
MIC
1
1
-
2
PHANTOM
3
=======
4
2
5
6
R111A
10
R113A 10
Q101A
2SC2240BL
VR101A 5KC
Q102A
2SC2240BL
JK103A
+
C114A 470uF/10V*
+
C106A 10u/25v
C104A 470p
C107A 470p
C110A 220P
C111A 33P
R112A 47k
R109A 10 R110A 33k
JK102A
R117A 8k2C108A
220p
C109A 220p
R119A 2K2
+ -
U101B
NJM2068LD
5 6
7
84
R118A 2k2
R123A
24k C115A 10P
R124A 20
R120A 4K7 R121A 4K7
R131A
680
+ -
U103A
NJM2068LD
3 2
1
84
C113A
0.01uF
+
C132A 47u/25v
R145A
180
R146A 100K
+
C133A 10u/25v
R147A 5k6
C134A 100p
C135A 100p
C136A 100p
R150A
5k6
R149A
5k6
+
C137A 47u/25v
VR105A 20KA
R151A 18k
R152A 18k
R153A 36k R154A 36k
C139A 100p
R156A 220
R163A
15K
R165A
18k
+
C105A 10u/25v
R108A 4k7
R158A
220
R164A
15K
SW102A SW DPDT
R155A 3K 1/4W
LD102A LED
C123A 0.015u
R130A 10K
R135A
10K
C125A
0.0039u
R132A
2k7
VR102A 50KB C.C
C128A 0.01uF
C129A 0.01uF
VR104A 50KB C.C
R137A
680
VR103A 50KB C.C
C126A 27pF R136A
2k7
+
C130A 4.7u/50v
R139A 100K
Q103A
2SC1815Y
R140A 8k2
R143A 100K
R142A 4K7
R141A 100K
C131A 0.047uF
Q104A
2SA1015Y
R144A
2K7 1/4W
LD101A LED
R138A 10
C117A
0.22u/25V
C120A 100P
C121A 27P
R129A 200K
R128A
200K
C124A 0.012u
R133A
10K
R134A
2k7
R127A 100K
VR108A
50KB C.C
R161A 4K3
R162A
4K3
SW103A SW DPDT
R160A 3K3 1/4W
LD103ALED
VR107A 20KA
C141A 0.01uF
R159A 10C140A
0.01uF
+
C142A 47u/25v
+ -
U103B
NJM2068LD
5 6
7
84
SW104A
SW DPDT
+ -
U102A
NJM2068LD
3 2
1
8 4
+
C145A 10u/25v
R167A 10K
+
C144A 10u/25v
C148A 100p
C116A 10P
+ -
U101A
NJM2068LD
3 2
1
84
R116A 8k2
R122A
24k
C118A 0.022u
R126A
100K
C119A 0.022u
+ -
U102B
NJM2068LD
5 6
7
84
C127A 100p
R115A 100k
+
C138A
10u/25v
VR109A 10KA
VR106A 20KA
C143A 0.001uF
C146A 0.001uF
C122A 0.01u
R125A 5K1 R168A 5K1
R166A
10K
R157A 18k
R148A
5k6
R114A 100k
C112A
0.01uF
+
C102A 10u/50v
R107A
47k
+
C101A
47u/63V LN
+
C103A
10u/50v
BC102A
300
JK101A XLR JACK
R105A 33k
R104A 100K
BC101A 300
R101A 390 1/4W
R102A 6K8 1/4W
R106A
10
SW101A SW DPDT
R103A
6K8 1/4W
MONI 1 PFL/AFL L EFFECT ST R MONI 2 PFL/AFL R ST L
Page7
PHONIC CORPORATION
POWERPOD 1860 SERVICE MANUAL
CHANNEL 1~4 SCHEMATIC
CHANNEL 1~8 PCB
