Phonocar VM012 - Device Connections and Interface; Rear Panel Connections Guide

4
IT-ENConnessioni • Connections
1
3
4
2
PARKING
REVERSE
WHEEL KEY 1
WHEEL KEY 2
GND
GND
AUX IN VIDEO
AUX IN R
AUX IN L
AUX IN L
AUX IN R
CAMERA
CAMERA POWER
GRIGIO / GREY
GIALLO / YELLOW
ROSSO/RED
GRIGIO-BIANCO / GREY-WHITE
ROSSO/RED
BIANCO/WHITE
NERO / BLACK
GIALLO / YELLOW
NERO / BLACK
GRIGIO / GREY
ROSSO/RED
USCITA AUDIO ANTERIORE SX - LEFT FRONT AUDIO OUTPUT
USCITA AUDIO ANTERIORE DX - RIGHT FRONT AUDIO OUPUT
USCITA AUDIO POSTERIORE SX - LEFT REAR AUDIO OUTPUT
USCITA AUDIO POSTERIORE DX - RIGHT REAR AUDIO OUTPUT
USCITA SUB WOOFER - SUB WOOFER OUTPUT
REMOTE AMPLIFICATORE - AMPLIFIER REMOTE
LINEA 1 COMANDI AL VOLANTE - SWC LINE 1
LINEA 2 COMANDI AL VOLANTE - SWC LINE 2
MASSA - GROUND
MASSA - GROUND
INGRESSO VIDEO - VIDEO INPUT
INGRESSO AUDIO DX - RIGHT AUDIO INPUT
INGRESSO AUDIO SX - LEFT AUDIO INPUT
INGRESSO AUDIO SX - LEFT AUDIO INPUT
INGRESSO AUDIO DX - RIGHT AUDIO INPUT
INGRESSO RETROCAMERA - REAR CAMERA INPUT
ALIMENTAZIONE RETROCAMERA - REAR CAMERA POWER
BLU-NERO/BLUE-BLACK
MARRON/BROWN
FRENO A MANO (COLLEGAMENTO OBBLIGATORIO)
HAND-BRAKE (CONNECTION ABSOLUTELY NECESSARY)
ATTIVAZIONE RETROCAMERA
REAR-CAMERA ACTIVATION
5
FRONT OUT L
FRONT OUT R
REAR OUT L
REAR OUT R
SUB WOOFER
AMP CONT
ROSSO/RED
BLU/BLUE
BIANCO/WHITE
BLU/BLUE
BIANCO/WHITE
ROSSO/RED
MIC
USB
APPLE CARPLAY / ANDROID AUTO
USB
GPS
1
2 5
3 4
MICRO SD CARD
NAVIGATION
RADIO FM-AM
DAB+
