PIAB piCOMPACT 23 SMART - 4.2 Pneumatic Diagrams; NC and NO Configurations

ManualpiCOMPACT
®
23 SMART IO-Link Ready 2 channelPage 10/24
Installation
4.2 Pneumatic diagrams
Note!
Filter and vacuum sensor are optional
4.2.1 NC and NO
Figure 3
2
1
•
•
2
1
•
•
2
1
•
•
2
1
•
•
1. Compressed air, 2. Vacuum, 3. Exhaust.
Without
non-return
valve
With
non-return
valve
Vacuum NC Vacuum NO
