PIAB piCOMPACT 23 SMART - 5. Technical Data; Pneumatic Technical Information; General Electric Characteristics; Valve Module Specifications

ManualpiCOMPACT
®
23 SMART IO-Link Ready 2 channelPage 20/24
Technical data
5. Technical data
Pneumatic technical information
Description Unit Value
COAX
®
SX12 COAX
®
SX42
X1 X2 X1 X2
Feed pressure, pump at opt. MPa [psi] 0.504 [73.2] 0.515 [74.7] 0.47 [68.2] 0.54 [78.3]
Feed pressure, nozzle at opt. MPa [psi] 0.5 [72.5] 0.43 [62.4]
Max vacuum at opt. pressure -kPa [-inHg] 85 [25] 90 [26.6]
Air consumption at opt. pressure Nl/s [scfm] 0.72 [1.52] 1.44 [3.05] 2.21 [4.68] 4.42 [9.36]
Max vacuum flow at opt. pressure Nl/s [scfm] 1.22 [2.58] 2.44 [5.16] 3.46 [7.33] 6.92 [14.7]
Flow, blow off at 0.5
MPa [72.5 psi]
No counter pressure
/ Counter pressure
0.1 MPa [14.5 psi]
Without ABO 0-2.3/0 [0-0.08/0] 0-4.3/0 [0-0.15/0]
With ABO Nl/s [scfm] 0-2.8/2.7 [0-0.1/0.1] 0-4.4/4.3 [0-0.16/0.15]
General electric characteristic
Description Unit Value
Supply voltage V 24 ±10% V
Typical current consumption Typical current consumption mA <200 mA
Valve module
Description Note
Function on/off Normally closed (NC*)/normally open (NO)/ Bi-stable
Function blow-off Normally closed (NC)
Manual override (optional) Yes, non-locking push style
Other data/Environmental data
Description Note
Temperature range -10 - 50°C [14-122°F]
Air humidity at +38°C % RH 90
Materials PA, NBR, SS, POM, TPE, FPM, Brass, ALU, Cu, ST, (PC)
*NC fail-safe version is available (power off - NO). In
running mode the valve behaves like a NC valve but
if power is cut the valve goes into NO-mode leaving
compressed air for continuous vacuum.
**Electrically activated.
