Steering column
Refitting
Upper and lower seat on chassis
Lower and upper seating on the chassis
LOWER AND UPPER SEATING ON THE CHASSIS
Titolo Durata/
Valore
Testo
Breve (<
4000 car.)
Indirizzo
Immagine
Lower and
upper
seating on
the chas-
sis
Steering bearing
Steering bearing upper seat
Removal
Lower and upper races from frame
To remove the bearing seats from the chassis, use
the appropriate tool as shown in the figure.
N.B.
To remove the lower seating of the lower bearing
just use a screwdriver as a lever between the seat-
ing and the shell.
LOWER AND UPPER SEATING FROM THE CHASSIS
Titolo Durata/Valore Testo Breve (< 4000
car.)
Indirizzo Immagine
Lower and upper seat-
ing from the chassis
Washer and upper bearing upper seat
After removing the upper seating, tilt the vehicle to
a side and take out the steering tube making sure
mudflaps have been removed and the calliper dis-
connected.
Suspensions Fly 125 - 150 4T
SUSP - 162
