Fuel supply Gravity feed, unleaded petrol,
through carburettor.
Lubrication Engine lubrication with lobe pump
(inside the crankcase) controlled
by chain and double filter: mesh
and centrifugal.
Cooling Forced-circulation air cooling.
Transmission With automatic expandable pulley
variator, torque server, V-belt,
automatic clutch, gear reduction
unit.
Fuel tank In plastic, with a capacity of ~ 7.5 l
(approximate value, including ~ 1.2
l reserve)
Front suspension with telescopic fork.
Rear suspension fitted with spring and coaxial
hydraulic shock absorber. Chassis
to engine support with swinging
arm.
Front wheel With 2.15 X 10" rims
Rear wheel With 3 X 10" rims
Front tyre 100/80-10"
Rear tyre 120/70-10"
Exhaust muffler Absorption type.
Electronic ignition Electronic ignition device with
incorporated HV coil.
Chassis Single spar and stamped sheets.
53
