Front brake disc brake with hydraulic control
(lever on the right side of the
handlebar).
Rear brake Drum brake with expanding shoes,
controlled mechanically (lever on
the left side of the handlebar ).
Kerb weight in running order 84 kg
Maximum load Driver only.
Engine oil Capacity: approx. 850 cm³
Engine oil (change) 850 cm³
Rear hub oil Quantity: approx. ~80 cm³
TECHNICAL DATA 100
ENGINE Single-cylinder, four-stroke
Bore 50 mm
Compression ratio 10.5 ÷ 11.5 : 1
Ignition advance (before TDC) 8° at 1800 to 2000 rpm
24° at 5000 to 6000 rpm
Spark plug NGK CR8EB
Depression carburettor KEIHIN CVK Ø 18 mm
Engine idle speed (100 cc) ~ 1500 ± 150 rpm
valve clearance intake: 0.10 mm - exhaust: 0.10
mm
54
