Max. speed According to current legislation
TECHNICAL DATA 100
Width 735 mm
Length 1880 mm
Maximum height 1150 mm
Wheelbase 1340 mm
Fuel system Gravity feed, with unleaded petrol
(with a minimum octane rating of
95) with carburettor.
Lubrication engine lubrication with lobe pump
(inside the crankcase) controlled
by chain and double filter: mesh
and centrifugal.
Cooling Forced-circulation air cooling.
TRANSMISSION With continuously variable
transmission, torque server, V belt,
automatic clutch, gear reduction
unit.
Main and supplementary fuel tank
(including ~ 1.2 l reserve) (100 cc)
~ 7 l
Front suspension Mechanical telescopic fork with 30
mm stems.
Front tyre size 100/80-10''
Rear tyre size 120/70-10''
55
