Pihernz Superstar 3900 - Supplied Articles and Optional Accessories; Included Equipment; Available Optional Accessories; Installation Guide

English - 20 -
SUPPLIED ARTICLES:
CB-27 radio Handheld
microphone
Mounting bracket Microphone
hanger
Non-slip mat DC power cable Screws for bracket Pads for bracket
Adjusting screws Spare fuse
(10 A, 250 V)
Self-tapping screws Pads
OPTIONAL ACCESSORIES
:
USB programming
cable
External speaker
INSTAL
L
A
T
ION:
Choose the most appropriate location from a simple and
practical point of view. The radio should not interfere with
the driver or make the use of vehicle controls and controls
difficult.
1. Using the self-tapping screws and pads (2 units) to fix
the bracket.
2. Put the Non-slip mat on the 2 ends of the bracket and
put in the radio. Then insert the adjusting screws and check
careful each screws, make sure the screws and machine will not lose when the car moves.
3. Choose suitable angle by means the 3
screw holes in the sides of bracket.
