Overall length 2385 / 2865* mm
Overall width 1200 mm
Height (with suntop) 1910 mm
Height (without suntop) 1200 mm
Seating capacity 2 Passengers
+2 Passengers (Optional)
Turning radius 3,0 mt
Weight (without batteries) 305 kg
Weight (with batteries) 475 kg
Wheelbase 1640 mm
Maximum speed (forward) 24 km/h
Maximum speed (reverse) 8 km/h
Battery 6 pcs x 8V
Parking brake Foot-operated multi-lock
Electro-magnetic (Optional)
Motor type High Eciency AC motor
Motor power 4kW,6kW
Chassis Steel Construction
Towing Capacity 500 kgs
Tires
Front 18x8,5-8 6-ply**
Rear 18x8,5-8 6-ply**
Maximum slope 25%
Charger 220 VAC@8 1A /48 V
Ground clearance 100 mm
Standard warranty 2 Years
* Overall lenght of vehicle equipped with extended suntop
** Turf or road type tires
PC-2 Technical Specication
