PC-6 Technical Specication
Overall length 4065 / 4175* mm
Overall width 1300 mm
Height (with suntop) 1990 mm
Height (without suntop) 1200 mm
Seating capacity 6 Passengers
+2 Passengers (Optional)
Turning radius 5,6 mt
Weight (without batteries) 525 kg
Weight (with batteries) 750 kg
Wheelbase 3320 mm
Maximum speed (forward) 24 km/h
Maximum speed (reverse) 8 km/h
Battery 8 pcs x 6V
Parking brake Foot-operated multi-lock
Electro-magnetic (Optional)
Motor type High Eciency AC motor
Motor power 10kW
Chassis Steel Construction
Towing Capacity 1000 kgs
Tires
Front 20,5x8-10 6-ply**
Rear 20,5x8-10 6-ply**
Maximum slope 25%
Charger 220 VAC@8 1A /48 V
Ground clearance 150 mm
Standard warranty 2 Years
* Overall lenght of vehicle equipped with extended suntop
** Road type tires
