Page #10 background image
PNOZ X4
Operating Manual PNOZ X4
19894-EN-07
10
Wiring
Please note:
} Information given in the "Technical details [ 15]" must be followed.
} Outputs 13-14, 23-24, 33-34 are safety contacts; output 41-42 is an auxiliary contact
(e.g. for display).
} Auxiliary contact 41-42 shouldnot be used for safety circuits!
} Do not connect undesignated terminals.
} To prevent contact welding, a fuse should be connected before the output contacts (see
Technical details [ 15]).
} Calculation of the max. cable runs l
max
in the input circuit:
R
lmax
R
l
/ km
I
max
=
R
lmax
= max. overall cable resistance (see Technical details [ 15])
R
l
/km = cable resistance/km
} Use copper wire that can withstand 60/75°C.
} Sufficient fuse protection must be provided on all output contacts with capacitive and in-
ductive loads.
} Do not switch low currents using contacts that have been used previously with high cur-
rents.
} When connecting magnetically operated, reed proximity switches, ensure that the max.
peak inrush current (on the input circuit) does not overload the proximity switch.
} On 24 VDC devices:
The power supply must comply with the regulations for extra low voltages with protect-
ive electrical separation (SELV, PELV) in accordance with VDE 0100, Part 410.
} Ensure the wiring and EMC requirements of IEC 60204-1 are met.
Important for detection of shorts across contacts:
As this function for detecting shorts across contacts is not failsafe, it is tested by Pilz during
the final control check. If there is a danger of exceeding the cable runs, we recommend the
following test after the installation of the device:
1. Unit ready for operation (output contacts closed)
2. Short circuit the test terminals S12, S22 for detecting shorts across the inputs.
3. The unit's fuse must be triggered and the output contacts must open. Cable lengths in
the scale of the maximum length can delay the fuse triggering for up to 2 minutes.
4. Reset the fuse: remove the short circuit and switch off the supply voltage for approx. 1
minute.

Other manuals for Pilz PNOZ X4

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Pilz PNOZ X4 and is the answer not in the manual?

Pilz PNOZ X4 Specifications

General IconGeneral
Supply Voltage24 V DC
Contacts3 N/O, 1 N/C
Width45 mm
Depth121 mm
MountingDIN rail
PL according to EN ISO 13849-1PL e
Category according to EN 954-14
SIL according to IEC 61508SIL 3
Max. switching current6 A
Protection classIP20
Operating Temperature-10 °C to +55 °C
Stop Category0
SIL CL according to EN IEC 62061SIL CL 3
Number of safe inputs2
Number of safe outputs3
Operating temperature range-10 °C to +55 °C
