Pilz PNOZ X4 User Manual

PNOZ X4
Operating Manual PNOZ X4
19894-EN-07
15
Technical details
Order no. 774730 – 774734
See below for more order numbers
General 774730 774731 774734
Approvals
CCC, CE, EAC (Euras-
ian), TÜV, cULus Listed
CCC, CE, EAC (Euras-
ian), TÜV, cULus Listed
CCC, CE, EAC (Euras-
ian), TÜV, cULus Listed
Electrical data 774730 774731 774734
Supply voltage
Voltage 24 V 24 V 110 V
Kind DC AC AC
Voltage tolerance -15 %/+10 % -15 %/+10 % -15 %/+10 %
Output of external
power supply (AC) – 5 VA 5 VA
Output of external
power supply (DC) 2,5 W – –
Frequency range AC – 50 - 60 Hz 50 - 60 Hz
Residual ripple DC 160 % – –
Duty cycle 100 % 100 % 100 %
Max. inrush current im-
pulse
Current pulse, A1 1,7 A – –
Pulse duration, A1 1,5 ms – –
Inputs 774730 774731 774734
Number 2 2 2
Voltage at
Input circuit DC 24 V 24 V 24 V
Start circuit DC 24 V 24 V 24 V
Feedback loop DC 24 V 24 V 24 V
Current at
Input circuit DC 40 mA 40 mA 40 mA
Start circuit DC 70 mA 90 mA 90 mA
Feedback loop DC 70 mA 90 mA 90 mA
Min. input resistance at
power-on 165 Ohm 165 Ohm 165 Ohm

Pilz PNOZ X4 Specifications

General

Supply Voltage	24 V DC
Contacts	3 N/O, 1 N/C
Width	45 mm
Depth	121 mm
Mounting	DIN rail
PL according to EN ISO 13849-1	PL e
Category according to EN 954-1	4
SIL according to IEC 61508	SIL 3
Max. switching current	6 A
Protection class	IP20
Operating Temperature	-10 °C to +55 °C
Stop Category	0
SIL CL according to EN IEC 62061	SIL CL 3
Number of safe inputs	2
Number of safe outputs	3
Operating temperature range	-10 °C to +55 °C
