7-1Operating Manual: PSS(1) DI2O Z
Technical Details
Electrical data
Supply voltage
Tolerance range
Current consumption
Galvanic isolation
Polarity protection
Connection type
Outputs
Number of outputs
Potential isolation
Status display
Output current at “1” signal
Total load capacity
Permitted range
Short circuit protection
Limitation of inductive switch-off at the
load
Simultaneity
Residual current at “0” signal
Output signal level
“1” signal (high) and
2.5 A load:
“0” signal (low):
Output switch delay
Off time during self test
Inputs
Number of inputs
Potential isolation
Input signal level
“1” signal (high)
“0” signal (low):
Input current
24 VDC
20 ... 30 VDC including residual ripple
480 mA via backboard bus
Yes (optocoupler, converter)
Yes
Screw terminals, max. 2.5 mm
2
(AWG 12)
8
Yes
One LED per output
2 A
10 A
0 ... 2.5 A
Electronic
-UB
100 % up to max. 10 A
Test pulses: 5 mA for max. 800 µs
UB - 2 VDC at 2.5 A
12 VDC at both output terminals
50 µs
< 200 µs
16
Yes
+15 ... +30 VDC
-3 ... +5 VDC
Typ. 6 mA
