To insert the Battery Pack into the Drive pack, hold the Drive pack in one
hand and Battery Pack in the other hand. Make sure the connector to the
Drive pack is facing the battery slot. Bring the two together and gently let the
Battery Pack slip into the battery slot of the Drive pack.
Once the Battery Pack is completely inserted, the fastening lid will
automatically lock the Battery Pack.
