4
[N.B]
The real vertical deviation in V/div is equal to the attenuation
factor multiplied by the range of vertical deviation selected on
the oscilloscope. It will be doubled in the case of use of a 50 Ω
load.
Example:
With the probe on factor x 200, the oscilloscope on 0.5 V/div,
the real vertical deviation is 200 x 0.5 = 100 V/div.
With a 50Ω load on the input of the oscilloscope the deviation
becomes 200 V/div.
200
Real Deviation In V/div
1 50 20
1000.5 25 10
400.2 10 4
200.1 5 2
1050 m 2.5 1
420 m 1 0.4
210 m 0.5 0.2
15 m 0.25 0.1
0.42 m 0.1 40 m
DP-25 Instruction Manual
Vertical Deviation on the
Oscilloscope in V/div
6. MAINTENANCE
For maintenance, only use specified spare parts.
The manufacturer can not be held responsible for any accident
arising following a repair made other than its after sales service or
approved repairers.
x 200 x 50 x 20
