DP-25 HIGH VOLTAGE DIFFERENTIAL PROBE
1
1. FEATURES
The DP-25 differential probe provides a safety means for
measuring differential voltage to all models of oscilloscopes.
The DP-25 converts the high differential voltage (≦1400Vpeak)
into a low voltage (≦7.0V, with reference to the earth) and display
on the oscilloscopes.
The DP-25 is designed to operate with the 1MΩimpedance
oscilloscopes. When combine with the 50Ω load, the attenuation
will be 2 times.
We recommend to use PINTEK PL-10 with DP-25 to expand the
measuring with DMM to observe more accurate measurement.
The accuracy of oscilloscope is 3% and the DMM is less than 1%.
NOTE: If you connect DP-25 to the DMM without PL-10, the
accuracy will be higher than 10%.
2. SPECIFICATIONS
(1) Bandwidth:
DC - to 25 MHz (-3 dB) for x 50, x 200
DC - to 15 MHz (for attenuation x 20)
(2) Attenuation: x 20, x 50, or x 200
(3) Accuracy: +/- 2%
(4) Voltage Input Ranges (DC + AC peak to peak)
≦ 140 Vp-p for x 20, (i.e about 45 Vrms or DC)
≦ 350 Vp-p for x 50, (i.e about 110 Vrms or DC)
≦ 1400 Vp-p for x 200, (i.e about 450 Vrms or DC)
(5) Permitted Max Input Voltage
Max differential voltage: 1400 V (DC + AC peak to peak) or
450Vrms
Max voltage between each input terminal and ground:
600 Vrms
