16
Rok-Bak & Pad Change
1. Close the valve on the propane cylinder, allow the
engine to stop and turn the machine OFF.
2. Remove the propane cylinder.
3. Raise the handle to the full-up position (about a 45°
angle).
4. Lift up on the front of the deck rocking the machine
back until it rests on the handle grips.
5. Remove centering device and inspect pad. If pad
has worn to less than a 1/4” (6mm) thick, replace it.
CAUTION! Carefully inspect the pad holder for cracks
or damage. Replace if necessary.
WARNING! A damaged pad holder rotating at high
speeds may be an extreme hazard if it should come
apart.
6. When lowering the machine down, do not drop the
machine. Slowly lower the machine to the floor until
the wheels are on the ground.
Wheel Adjustment
1. Close the valve on the propane cylinder, allow the
engine to stop and turn the machine OFF.
2. Remove the propane cylinder.
3. Raise the handle to the full-up position (about a 45°
angle).
4. Rock the machine by lifting up on the front of the
machine until it rests on the handle grips.
5. Remove the pin that retains each wheel and relocate
to the desired wheel position.
NOTE: To increase pad pressure (more aggressive)
move wheels to rear of machine. To decrease pad
pressure (less aggressive) move wheels toward the
front of machine.
Handle Adjustment
1. The height of the handle can be adjusted by raising
or lowering the handle.
2. Loosen the handle adjustment lever on the side of
the handle by turning is counter-clockwise (toward
the rear of the machine).
NOTE: The handle adjustment lever will ratchet. Pull
outward and pivot the lever in the desired direction.
3. Move the handle to the desired height and tighten the
handle adjustment lever.
