41
Item Ref. No. Description Qty
1 KA160600742 PIPE, INTAKE 1
2 KA110137046 PRECLEANER, AIR 1
3 KA490657007 FILTER, OIL 1
4 KA920702112 PLUG, SPARK, NGK, BPR4ES 2
5 KA110130752 ELEMENT, FILTER, AIR 1
6 MP367700 PULLEY, 4.00” 1
7 MP7802 KEY, 1/4” X 1-1/2” 1
8 NB2463 SCREW, SET, 5/16” X 3/8” 2
9 MP364900 MUFFLER, CATALYST 1
10 KA110607016 GASKET, MUFFLER 2
11 MP455601 BRACE, MUFFLER 1
12 NB068500 BOLT, HEX, 1/4” X 3-1/2” 2
13 NB9545 NUT, FLANGE, 1/4” 2
14 NB8125 CLAMP, 1/4” ID 1
15 NB8130 CLAMP, 3/4” ID 1
16 MP044800 ADAPTER, 1/8” NPT 1
17 MP019200 SWITCH, PRESSURE, OIL 1
18A MP015200 PLUG, SENSOR 1
18B MP466500 SENSOR, OXYGEN 1
19 NB2460 HOSE, VACUUM, 5/32” 27”
Engine Assembly (continued)
Item Ref. No. Description Qty
20 NB2470 HOSE, FUEL, 3/8” 26”
21 KA461DA0800 WASHER, LOCK, M8 4
22 KA922107027 NUT, HEX, M8 4
23 NB7282 CLAMP, HOSE 2
24 MP371300 FILTER, INTAKE, ENGINE 1
25 MP371200 CAGE, INTAKE, ENGINE 1
26 MP072300 VALVE, DRAIN, OIL 1
27 NB2460 HOSE, VACUUM, 5/32” 33”
28 NB065000 BOLT, HEX, M8 X 16 1
29 NB9267 WASHER, FLAT, 5/16” 1
30 NB6111 WASHER, LOCK, 5/16” 1
31 MP4515 TUBING, DRAIN, OIL 18”
32 NB1621 PLUG, CAP 1
33 NB3350 WASHER, FLAT, 1/4” 2
34 MP455900 SPACER, 1/4” ID 2
35 MP371700 SPACER, 1.02” ID 1
36 MP4805 SPACER, BOTTOM, CLUTCH 1
37 NB005800 BOLT, HEX, 7/16” X 1-1/2” 1
38 MP4787 CLUTCH, ASM. 1
39 MP4790 TUBING, NEOPRENE 2.5”
