43
Handle Assembly (continued)
Item Ref. No. Description Qty
1 MP366500 HANDLE, BASE 1
2 MP366800 HANDLE, TOP 1
3 NB9460 BOLT, CARRIAGE, 3/8” X 4” 2
4 NB3450 WASHER, FLAT, 3/8” 2
5 NB3267 NUT, LOCK, 3/8” 1
6 MP366900 GRIP, HANDLE 2
7 MP368000 CABLE, THROTTLE 1
8 NB4382 SCREW, #8 X 1/2” 2
9 MP5950 LEVER, ADJUST, HANDLE 1
10 MP1230 BASE, BOX, SWITCH 1
11 MP376000 SWITCH, ASM. 1
12 MP087100 LEVER, SWITCH 2
13 MP9606 SPRING, LEVER 2
14 MP1210 COVER, BOX 1
15 NB5366 SCREW, #8 X 1-1/4” 4
