Old Deck Assembly (continued)
Item Ref. No. Description Qty
1A MP066801 LINER, 28”, ASM. 1
1B MP073300 LINER, 24”, ASM. 1
1C MP376200 LINER, 21”, ASM. 1
2A MP8300 HOOK, VELCRO, 1” 74”
2B MP8300 HOOK, VELCRO, 1” 85”
2C MP8300 HOOK, VELCRO, 1” 98”
3 MP139900 BUSHING, STEEL 1
4 NB038800 BOLT, SH, 1/4” X 1-1/4” 1
5 NB9645 WASHER, FLAT, #10 5
6 NB020600 RIVET, 3/16” X 3/4” 5
7 MP197100 SHIM, CAMBER, 1/32” 1
8 MP197000 SHIM, CAMBER, 1/16” 1
9A MP447700 SPINDLE, 9.25”, ASM. (28”) 1
9B MP7235 SPINDLE, 7.25”, ASM. (24”) 1
9C MP107700 SPINDLE, 6.75”, ASM. (21”) 1
10 NB6864 BOLT, HEX, 1/2” X 1-1/4” 4
11 NB9269 WASHER, FLAT, 7/16” 4
12 MP071800 TENSIONER, BELT 1
13 NB6044 BOLT, HEX, 3/8” X 1-1/4” 1
14 NB3450 WASHER, FLAT, 3/8” 1
15 MP012801 CASTER, 2-1/2” 1
16 NB003100 NUT, JAM, HEX, 1/2” 1
17 MP371501 BRACKET, WHEEL, 5” X 2” 2
Item Ref. No. Description Qty
18 NB6545 BOLT, HEX, 5/16” X 1” 4
19 NB3265 NUT, LOCK, 5/16” 6
20 MP352600 WHEEL, 5” X 2” 2
21 LX2105 CLIP, HITCH PIN 2
22 NB053400 PIN, CLEVIS, 1/2” X 3-1/2” 2
23A MP064800 SCOOP, VAC, 28” 1
23B MP064700 SCOOP, VAC, 24” 1
23C MP064600 SCOOP, VAC, 21” 1
24 NB019100 BOLT, HEX, 1/4” X 3/4” 3
25 NB3350 WASHER, FLAT, 1/4” 3
26 NB6110 WASHER, LOCK, 1/4” 3
27 MP336200 STRAP, BUMPER 1
28 NB063400 RIVET, 3/16” X 1.00” 4
29 NB9645 WASHER, FLAT, #10 7
30 NB9745 BOLT, HEX, 5/16” X 3/4” 2
31 MP067600 TUBE, DUST 1
32 MP065200 SEAL, TUBE, DUST 1
33 NB063300 SCREW, HEX, #10 X 1” 3
34 NB9735 NUT, LOCK, #10 3
35 MP8310 STUDS, HOOK, VELCRO 1
36 MP124700 BAG, VACUUM 1
37 MP371601 BRACKET, SUPPORT, BAG 1
38 MP371400 BUMPER, ROK-BAK 1
