Pioneer Eclipse PE420BU - Page 53

53
Regulator, Switch Panel & Solenoid Assembly (continued)
Item Ref. No. Description Qty
1 SA026300 REGULATOR, LP 1
2 MP017900 ADJUSTMENT, FUEL, ASM. 1
3 MP317500 FUELOCK, ASM. 1
4 MP367300 HOSE, FUEL, 13” 1
5 MP4330 FITTING, ELBOW 1
6 MP4500 COUPLER, REGO 1
7 MP371100 FITTING, 3/16” HB 1
8 MP372400 FITTING, ELBOW, 1/8” 1
9 MP367100 SOLENOID, STARTER 1
10 MP366700 CABLE, BATTERY, 9” 1
11 MP120900 CABLE, BATTERY, 14” 1
12 MP354900 WIRE, SOLENOID 1
13 MP402300 MODULE, ECOSENSE, ASM. 1
14 MP367400 PANEL, SWITCH 1
15 MP199000 SWITCH, IGNITION 1
16 KC4834001 KEY, IGNITION 1
17 SS900001 LABEL, SWITCH 1
18 MP280400 METER, HOUR / TACH 1
19 NB007400 SCREW, #8 X 1/2” 2
20 NB9710 NUT, #8 2
21 SA026300 REGULATOR, LP 1
22 MP4325
FITTING, 3325 X 4, REG TO
FUELOCK
2
23 MP509300 FITTING, TEE, 1/4” FNPT 1
24 MP509200 SWITCH, PRESSURE, 200 PSI 1
Item Ref. No. Description Qty
25 MP4330
FITTING, 49 X 6, REG TO
FUELOCK
1
26 MP367300 HOSE, FUEL, LP, 13”, ASM. 1
27 MP4332
FITTING, 1/4”, BRASS ELBOW,
FPT
1
28 MP317500 FUELOCK, 12 VOLT, ASM. 1
29 MP509600 MANIFOLD, SAFE STOP 1
30 MP4500
COUPLER, QUICK REGO,
FEMALE
1
31 MP4331
FITTING, 54 X 6, REG TO
FUELOCK
2
32 MP492000 LIGHT, RED, LED, 12V 1
33 MP151500
RELAY, BOARD, CIRCUIT,
PRINTED, 12V
1
34 NB007100 WASHER, FLAT, #6 2
35 MP509401 BRACKET, SAFE-STOP 1
36 NB020800 NUT, LOCK, NYLON, 6-32 2
37 MP509700 DECAL, OVERFILL WARNING 1
38 NB6110 WASHER, LOCK, 1/4” 2
39 MP509900
FITTING, 1/8” MNPT X 1/4”
FNPT
1
40 MP509800 SWITCH, PRESSURE, 6 PSI 1
41 MP017900 ADJUSTMENT, FUEL, ASM. 1
42 NB9515 SCREW, PAN HD, 6-32 X 1/2 2
43 NB015700 SCREW, CAP, HH, 1/4 -20 X 5/8 2
44 MP372400 FITTING, ELBOW, BRASS 1
45 MP371100
FITTING, BRASS, 1/4-28 x
3/16” HB
1
46 MP341500 SCREEN, INLET, REGULATOR 1
47 MP4340 HOSE, 12”, REGULATOR 1
