40” Deck Assembly (continued)
Item Ref. No. Description Qty
1 NB9269 WASHER, FLAT, 7/16” 12
2 MP393100 DECK, 40” 1
3 NB6864 BOLT, HEX, 1/2” X -1-1/4” 8
4 NB3450 WASHER, FLAT, 3/8” 3
5 NB008900 RIVET, 3/16” 12
6 MP139700 BUMPER, SKIRT 9 FT
7 RV005100 KNOB, HANDLE 3
8 NB6545 BOLT, HEX, 5/16” X 1” 4
9 MP393500 BRACKET, WHEE, 3” 1
10 MP336200 STRAP, BUMPER, ROK-BAK 1
11 NB063400 RIVET, 3/16” X 1.00” 4
12 MP371400 BUMPER, ROK-BAK 1
13 NB9645 WASHER, FLAT, #10 4
14 MP268800 BELT, B111 1
15 NB050200 BOLT, CARRIAGE, 3/8” X 1-1/2” 2
16 NB044900 BOLT, HEX, 3/8” X 4” 2
17 NB3265 NUT, LOCK, 5/16” 6
18 MP187200 SPRING, SUPPORT 1
19 MP455100 IDLER, FLAT, 5” 1
20 MP269100 SPINDLE, 9.75”, ASM. 2
21 MP038700 WHEEL, 3” 2
22 NB000100 BOLT, HEX, 5/16” X 1-3/4” 2
Item Ref. No. Description Qty
23 MP269400 PAD HOLDER, 21” 2
- MP012700 RETAINER, PAD (NOT SHOWN) 1
24 NB3267 NUT, LOCK, 3/8” 2
25 HH006000 EDGING, FELT, SKIRT
26 N/A N/A 2
27 MP399700 SPACER, .406” ID X 2.10”
28 NB010100 BOLT, CARRIAGE, 3/8” X 2”
29 LX2105 CLIP, HITCH PIN 2
30 MP371501 BRACKET, WHEEL 2
31 NB053400 PIN, CLEVIS, 1/2” X 3-1/2” 2
32 MP352600 WHEEL, 5” X 2” 2
33 MX1080 WASHER, FLAT, 3/8” 3
34 NB048001 BOLT, SPRING GUIDE, 6” 1
35 HH004000 BUSHING, ROD, SKIRT 6
36 MP311900 SPRING, COMP., 3” 2
37 HH000600 SHROUD, DUST, ASM. 1
38 MP262400 IDLE, FLAT, 3.2” 2
39 MP399600 SPACER, .406” ID X 1.95” 1
40 NB018600 WASHER, FLAT, 3/4” 3
41 NB053700 NUT, JAM, 3/4” 2
42 NB048101 BOLT, SPRING GUIDE, 5” 2
43 NB5520 BOLT, CARRIAGE, 3/8” X 1-1/4” 3
