SPECIFICATIONS
Amplifier Section
Continuous power output
(both channels driven at 20 Hz to 20 kHz)**
[A-307R]
T.H.D. 0.1 %, 8 Ω .................................... 45 W + 45 W*
T.H.D. 0.15 %, 4 Ω .................................. 65 W + 65 W*
[A-209R]
T.H.D. 0.1 %, 8 Ω .................................... 35 W + 35 W*
T.H.D. 0.15 %, 4 Ω .................................. 45 W + 45 W*
DIN Continuous power output
(both channels driven at 1 kHz)
[A-307R]
T.H.D. 1.0 %, 8 Ω ...................................... 55 W + 55 W
T.H.D. 1.0 %, 4 Ω ...................................... 80 W + 80 W
[A-209R]
T.H.D. 1.0 %, 8 Ω ...................................... 45 W + 45 W
T.H.D. 1.0 %, 4 Ω ...................................... 60 W + 60 W
Total harmonic distortion**
[A-307R]
20 Hz to 20 kHz, 22.5 W, 8 Ω ............................ 0.08 %*
[A-209R]
20 Hz to 20 kHz, 17.5 W, 8 Ω ............................ 0.08 %*
÷ Power output specification is for when power supply is
230 V.
Input sensitivity/impedance
PHONO (MM) ........................................... 2.8 mV/50 kΩ
[A-307R]
CD, TUNER, LINE, TAPE1/MD, TAPE2 MONITOR
.................................................................. 200 mV/50 kΩ
[A-209R]
CD, TUNER, LINE, TAPE1/CD-R/MD, TAPE2 MONITOR
.................................................................. 200 mV/50 kΩ
PHONO (MM) overload level
1 kHz, T.H.D. 0.1 % ............................................ 150 mV
Output level/impedance
TAPE1 REC, TAPE2 MONITOR REC ......... 200 mV/1 kΩ
Frequency response
PHONO (MM) .......................... 20 Hz to 20 kHz, ±0.5 dB
[A-307R]
CD, TUNER, LINE, TAPE1/MD, TAPE2 MONITOR
.................................................... 5 Hz to 100 kHz,
+0
–3
dB*
[A-209R]
CD, TUNER, LINE, TAPE1/CD-R/MD, TAPE2 MONITOR
.................................................... 5 Hz to 100 kHz,
+0
–3
dB*
Power Supply/Miscellaneous
Power requirements .................. AC 220 – 230 V, 50/60 Hz
Power consumption
[A-307R] ................................................................. 140 W
[A-209R] ................................................................. 130 W
Dimensions (including knobs and other protruding parts)
.......................................420 (W) x 114 (H) x 307 (D) mm
Weight (without package)
[A-307R] ..................................................................5.9 kg
[A-209R] ..................................................................4.7 kg
Accessories
Remote control unit ........................................................... 1
Batteries (AA/R6P) ............................................................. 2
Power cord (Rated current 2.5 A) ...................................... 1
Operating instructions ........................................................ 1
Warranty card..................................................................... 1
NOTE:
Specifications and design are subject to possible modifica-
tions without notice, due to improvements.
* Measured with DIRECT button set to on.
**Measured by Audio Spectrum Analyzer.
Published by Pioneer Corporation.
Copyright © 2000 Pioneer Corporation.
All rights reserved.
PIONEER CORPORATION 4-1, Meguro 1-Chome, Meguro-ku, Tokyo 153-8654, Japan
PIONEER ELECTRONICS [USA] INC. P.O. BOX 1540, Long Beach, California 90801-1540, U.S.A.
PIONEER ELECTRONICS OF CANADA, INC. 300 Allstate Parkway, Markham, Ontario L3R OP2, Canada
PIONEER ELECTRONIC [EUROPE] N.V. Haven 1087, Keetberglaan 1, 9120 Melsele, Belgium TEL: 03/570.05.11
PIONEER ELECTRONICS AUSTRALIA PTY. LTD. 178-184 Boundary Road, Braeside, Victoria 3195, Australia, TEL: [03] 9586-6300
PIONEER ELECTRONICS DE MEXICO S.A. DE C.V. San Lorenzo Num 1009 3er piso Desp. 302 Col. Del Valle, Mexico D.F. C.P. 03100 TEL: 5-688-52-90
<00B00ZF0P00>
Printed in <ARB7236-A>
Tone control
BASS ...................................................... ±8 dB (100 Hz)
TREBLE ................................................... ±8 dB (10 kHz)
Loudness contour (volume control set at –30 dB position)
........................................ +6 dB (100 Hz)/+4 dB (10 kHz)
Signal-to-Noise ratio (IHF short circuit, A network)
PHONO (MM, 5 mV input) ................................. 85 dB*
[A-307R]
CD, TUNER, LINE, TAPE1/MD, TAPE2 MONITOR
........................................................................... 106 dB*
[A-209R]
CD, TUNER, LINE, TAPE1/CD-R/MD, TAPE2 MONITOR
........................................................................... 106 dB*
Signal-to-Noise ratio (DIN, continuous power/50 mW)
PHONO (MM) ............................................ 71 dB/67 dB*
[A-307R]
CD, TUNER, LINE, TAPE1/MD, TAPE2 MONITOR
.................................................................. 91 dB/71 dB*
[A-209R]
CD, TUNER, LINE, TAPE1/CD-R/MD, TAPE2 MONITOR
.................................................................. 91 dB/71 dB*
