3. BASIC ITEMS FOR SERVICE
3.1 CHECK POINTS AFTER SERVICING
4. BLOCK DIAGRAM
There is not information to be shown in this chapter.
5. DIAGNOSIS
5.1 CONNECTOR FUNCTION DESCRIPTION
6. SERVICE MODE
There is not information to be shown in this chapter.
To keep the product quality after servicing, please confirm following check points.
demrifnocebotmetIserudecorP.oN
1 Confirm whether the customer complain has
been solved.
The customer complain must not be
reappeared.
Audio and operations must be normal.
2 Check the output sound. Audio and operations must be normal.
retfaecnaraeppastinotridrosehctarcsoNkcehcecnaraeppA3
receiving it for service.
See the table below for the items to be checked regarding video and audio:
Item to be checked regarding audio
Distortion
Noise
Volume too low
Volume too high
Volume fluctuating
Sound interrupted
