Pioneer GM-5400T Service Manual

GM-5400T/XJ/UC
13
5 678
56
7
8
C
D
F
A
B
E
(1) PACKING SECTION PARTS LIST
(2) CONTRAST TABLE
GM-5400T/XJ/UC, GM-5400T/XJ/EW5 and GM-5400T/XJ/ES are constructed the same except for the following:
Owner's Manual,Installation Manual
Mark No. Description Part No.
* 1-1 Caution Card See Contrast table (2)
* 1-2 Warranty Card See Contrast table (2)
1-3 Owner's Manual See Contrast table (2)
2 Cord Assy CZD5517
3 Polyethylene Bag CZE2962
4 Polyethylene Bag See Contrast table (2)
5 Unit Box See Contrast table (2)
6 Contain Box See Contrast table (2)
7 Cushion CZH6698
8 Screw Assy CEA5330
9 Screw BYC40P180FTB
* 10 Polyethylene Sheet CNM4338
Mark
No. Description Part No.
Mark No. Description GM-5400T/XJ/UC GM-5400T/XJ/EW5 GM-5400T/XJ/ES
* 1-1 Caution Card CZR5560 Not used Not used
* 1-2 Warranty Card CRY1276 CRY1279 Not used
1-3 Owner's Manual CZR5552 CZR5551 CZR5553
4 Polyethylene Bag CEG1351 *CZE2987 *CZE2987
5 Unit Box CZH6684 CZH6682 CZH6686
6 Contain Box CZH6685 CZH6683 CZH6687
Part No. Language
CZR5552 English, French, Spanish(Espanol)
CZR5551 English, Spanish(Espanol), German, French, Italian, Dutch, Russian
CZR5553 English, Spanish(Espanol), Portuguese(B), Arabic

Pioneer GM-5400T Specifications

General

Impedance	4 Ω
Frequency range	20 - 20000 Hz
Signal-to-Noise Ratio (SNR)	95 dB
Total Harmonic Distortion (THD)	0.03 %
Channels quantity	2 channels
Dimensions (WxDxH)	265 x 346 x 62 mm
Connectivity technology	Wired
Line-in	Yes
Product color	Black

Weight and Dimensions

Weight	3800 g
