Pioneer GM-5400T Service Manual

GM-5400T/XJ/UC
15
5 678
56
7
8
C
D
F
A
B
E
(1) EXTERIOR SECTION PARTS LIST
(2) CONTRAST TABLE
GM-5400T/XJ/UC, GM-5400T/XJ/EW5 and GM-5400T/XJ/ES are constructed the same except for the following:
Mark No. Description Part No.
1 Screw BBZ30P100FTC
2 Screw BBZ30P120FTC
* 3 Screw See Contrast table (2)
4 Screw BSZ26P060FTB
5 Screw BSZ30P060FTB
6 Holder See Contrast table (2)
7 Plate CZN8435
8 Plate CZN8438
9 Spacer CZN8440
10 Chassis CZN8441
11 Amp Unit See Contrast table (2)
12 Screw BBZ30P080FTB
13 Screw BBZ30P100FTC
> 14 Fuse(30 A) CEK1330
15 Pin Jack(JA101) CKB1068
16 Terminal(JA801) CKE1055
17 Terminal(JA501) CKE1057
18 Terminal(JA502) CKE1057
19 Terminal(JA802) CND2458
20 Terminal(JA803) CND2458
21 Terminal(JA804) CND2458
22 Terminal(JA805) CND2458
* 23 Bas Bar(1) CZN8425
* 24 Bas Bar(5) CZN8429
* 25 Bas Bar(3) CZN8427
26 Holder CZN8430
* 27 Heat Sink CZN8432
* 28 Heat Sink CZN8433
29 Sheet CZN8443
30 Screw PPZ30P100FNN
31 Case Unit See Contrast table (2)
32 Screw BBZ30H060FTB
* 33 Heat Sink See Contrast table (2)
34 Plate Assy See Contrast table (2)
35 Nut See Contrast table (2)
36 Screw PPZ30P100FTB
* 37 Washer See Contrast table (2)
38 Transistor(Q515,516) KTC3114
39 Transistor(Q523,524,525,526) 2SC5358
40 Transistor(Q527,528,529,530) 2SA1986
41 Transistor(Q805,806,807,808,809,810) FKV550N
42 Transistor(Q811) KTC2026
43 Transistor(Q812) KTA1046
44 Thermistor(TH701,702) CCX1057
45 Diode(D801) FML22S
46 Diode(D802) FML22R
47 Socket(J1) CKM1463
* 48 Seal CAN3984
49 Screw BBZ30P080FTB
50 Screw PPZ30P100FTB
51 Plate CZN8417
52 Earth Terminal(KN801) CZK2969
53 Screw PBZ30P120FTB
Mark
No. Description Part No.
Mark No. Description GM-5400T/XJ/UC GM-5400T/XJ/EW5 GM-5400T/XJ/ES
* 3 Screw BMZ40P250FTB Not used Not used
6 Holder CNV8522 Not used Not used
7 Plate CZN8435 CZN8435 CZN8435
11 Amp Unit CZW5578 CZW5577 CZW5577
31 Case Unit CZX6645 CZX6644 CZX6646
* 33 Heat Sink CZN8444 CZN8416 CZN8416
34 Plate Assy CZX6639 CZX6638 CZX6639
35 Nut NB40FTB Not used Not used
* 37 Washer WB45FTB Not used Not used

Pioneer GM-5400T Specifications

General

Impedance	4 Ω
Frequency range	20 - 20000 Hz
Signal-to-Noise Ratio (SNR)	95 dB
Total Harmonic Distortion (THD)	0.03 %
Channels quantity	2 channels
Dimensions (WxDxH)	265 x 346 x 62 mm
Connectivity technology	Wired
Line-in	Yes
Product color	Black

Weight and Dimensions

Weight	3800 g
