Pioneer M-IS21 - Page 33

M-IS21
15
Mark No. Description Part No.
Mark No. Description Part No.
D3351–D3354, D3361, D3362 1SS133
D3355, D3356 LT2A03
D3357, D3358 MTZJ10C
D3359, D3360 MTZJ18B
D3363, D3364 MTZJ39C
CAPACITORS
C3319, C3320 CCSQCH100D50
C3327, C3328 CCSQCH680J50
C3317, C3318 CEANP100M35
C3313, C3314 CEANP2R2M50
C3303, C3304 CEAT101M50
C3506–C3508 CEAT1R0M50
C3501, C3502, C3509, C3510 CEAT470M25
C3315, C3316 CKSQYB332K50
C3503, C3504 CKSQYB682K50
C3308 CKSQYB822K50
RESISTORS
R3353, R3354 RD1/4PU101J
R3510 RD1/4PU104J
Other Resistors RS1/10S J
OTHERS
CN3003 5P PLUG AKM7010
CN3006 11P PLUG AKM7011
POWER SUPPLY ASSY
SEMICONDUCTORS
IC33 PROTECTOR(1.25A) AEK7048
IC42 PROTECTOR(2A) AEK7067
IC32 NJM4558MD
IC23 NJM7805FA
IC24 NJM7905FA
Q33, Q43 2SB1566
Q32, Q3654, Q42 2SC1740S
Q3652 2SC2412K
Q3651 DTA143ES
Q3653 DTC124EK
D3654–D3656, D9021–D9024, D9026 1SS133
D9029 1SS133
D9030 MTZJ24B
D36, D46 MTZJ3.0B
D35, D45 MTZJ5.1B
D9027, D9028 MTZJ6.8C
CAPACITORS
C27, C28, C35, C45 CEAT100M50
C3652 CEAT101M16
C25, C26, C3651 CEAT1R0M50
C3654 CEAT220M35
C42, C43 CEAT470M16
C32, C33 CEAT470M25
C44 CKSQYB102K50
C3653, C9027, C9028 CKSQYF104Z50
RESISTORS
R35 RD1/2LMF121J
R45 RD1/2LMF910J
R3659 RD1/2PM330J
Other Resistors RS1/10S J
OTHERS
CN3002 14P PLUG AKM7012
PRIMARY ASSY
PRIMARY assembly has no service part.
SECONDARY ASSY
SEMICONDUCTORS
IC41 PROTECTOR(3.5A) AEK7017
IC31 PROTECTOR(4A) AEK7018
IC21, IC22 PROTECTOR(5A) AEK7019
IC11, IC12 PROTECTOR(7A) AEK7021
OTHERS
3001 12P CABLE HOLDER 51048-1200
HP ASSY
COILS AND FILTERS
L3992–L3994 CHIP BEADS VTL1096
CAPACITORS
C3991, C3995, C3996 CKSQYB472K50
RESISTORS
R3991, R3992 RS2LMF331J
OTHERS
3004 5P CABLE HOLDER 51048-0500
3991 MINI JACK AKN7003
J3004 5P JUMPER WIRE D20PYY0535E
METER ASSY
SEMICONDUCTORS
IC5601 NJM4558MD
Q5601 2SA1037K
Q5602 DTA124EK
Q5603, Q5604 DTC124EK
D5601, D5605, D5606 1SS133
D5608 MTZJ10B
D5604 MTZJ12B
D5607 MTZJ5.1B
CAPACITORS
C5603, C5607 CEAT1R0M50
C5604, C5605 CKSQYF104Z50
