1. SAFETY INFORMATION
(FOR USA MODEL ONLY)
1.SAFETY PRECAUTIONS
The following check should be performed for the con-
tinued protection of the customer and service technician.
LEAKAGE CURRENT CHECK
Measure leakage current to a known earth ground (water
pipe, conduit, etc.) by connecting a leakage current tester
such as Simpson Model 229-2 or equivalent between the
earth ground and al} exposed metal parts of the appliance
(input/output terminals, screwheads, metal overlays, con-
trol shaft, etc.). Plug the AC line cord of the appliance
directly into a 120V AC 60Hz outlet and turn the AC
power switch on. Any current measured must not exceed
0.5mA.
Reading should
Leakage | not be above
Device
current
19
5mA
ander tester
test
Test all
exposed metal
“surfaces
2-wire cord
Also test with
plug reversed + Earth
(Using AC adapter “ground
plug as required)
AC Leakage Test
(FOR EUROPEAN MODEL ONLY)
rVAROITUS!
LAITE SISALTAA LASERDIODIN, JOKA
LAHETTAA NAKYMATONTA, SILMILLE
VAARALLISTA = INFRAPUNASATEILYA
LAITTEEN SISALLA ON LASERDIODIN
LAHEISYYDESSA KUVAN 1, MUKAINEN
| VAROITUSMERKKI.
LASER
Kuva 1
Lasersateilyn
varoitusmerkki
rADVERSEL:
USYNLIG LASERSTRALING VED ABNING
NAR SIKKERHEDSAFBRYDERE ER UDE
AF FUNKTION UNDGA UDSAETTELSE
FOR STRALING.
VIKTIGT
APARATEN INNEHALLER LASER AV HOGRE
KLASS AN 1. INGREPP | APPARATEN BOR
GORAS AV SPECIELLT UTBILDAD PERSONAL.
ANY MEASUREMENTS NOT WITHIN THE LIMITS OUT.
LINED ABOVE ARE INDICATIVE OF A POTENTIAL
SHOCK HAZARD AND MUST BE CORRECTED
BEFORE RETURNING THE APPLIANCE TO THE
CUSTOMER.
2.PRODUCT SAFETY NOTICE
Many electrical and mechanical parts in the appliance
have special safety related characteristics. These are often
not evident from visual inspection nor the protection af-
forded by them necessarily can be obtained by using re-
placement components rated for voltage, wattage, etc. Re-
placement parts which have these special safety charac-
teristics are identified in this Service Manual.
Electrical components having such features are identified
by marking with a A\ on the schematics and on the parts
list in this Service Manual.
The use of a substitute replacement component which
does not have the same safety characteristics as the
PIONEER recommended replacement one, shown in. the
parts list in this Service Manual, may create shock, fire, or
other hazards.
Product Safety is continuously under review and new
instructions are issued from time to time. For the latest
information, always consult the current PIONEER Serv-
ice Manual. A subscription to, or additional copies of,
PIONEER Service Manual may be obtained at a nominal
charge from PIONEER.
WARNING!
DEVICE INCLUDES LASER DIODE WHICH
EMITS INVISIBLE INFRARED RADIA-
TION WHICH 1S DANGEROUS TO EYES.
THERE !S A WARNING SIGN ACCORDING
TO PICTURE 1 INSIDE THE DEVICE
CLOSE TO THE LASER DIODE.
LASER
Picture 1
Warning sign for
laser radiation
IMPORTANT
PIONEER COMPACT DISC PLAYER APPARA-
TUS CONTAINS LASER OF HIGHER CLASS
THAN 1. SERVICING OPERATION OF THE AP-
PARATUS SHOULD BE DONE BY A SPECIALLY
INSTRUCTED PERSON.
