PDP-425CMX
168
1234
1234
C
D
F
A
B
E
Multi Base Block
5
1
Remove the two screws.
2
Remove the one screw.
3
Remove the one screw.
4
Disconnect cables, as required.
5
Remove the multi base Block.
Multi base Block
1
1
3
2
5
VSIF Assy
MAIN Assy
