Pioneer PDP-425CMX

PDP-425CMX
58
1234
1234
C
D
F
A
B
E
C5375, C5376 CKSRYB222K50
RESISTORS
R5303 RAB4CQ101J
R5394-R5397 RS1/10SR2202F
R5376, R5377 RS1/10SR8200F
Other Resistors RS1/10S###J
OTHERS
CN5301 50P CONNECTER AKM1345
JA5371-JA5373 JACK AKN1075
MAIN BLOCK4
SEMICONDUCTORS
IC5605 BA7078BF
IC5601 BA7657F
IC5602 SM5301CS
IC5606 SN74LVC2G126DCTR
IC5604 TC74LCX157FTS1
IC5603 TC74VHC153FT
Q5602, Q5606 2SA1576A
Q5601, Q5603, Q5604 2SC4081
Q5607 DTC144EUA
COILS AND FILTERS
L5601 CHIP COIL BTH1100
L5602, L5603, L5606, L5607 CHIP COIL BTH1102
L5604, L5605 CHIP COIL BTH1104
CAPACITORS
C5625, C5629 (2.2/16) ACG1133
C5643, C5676 (4.7/16) ACG1134
C5672 (100/16) ACH1430
C5646-C5648 (47/6.3) ACH1444
C5645 CCSRCH101J50
C5670 CCSRCH471J50
C5658-C5663 CCSRCH4R0C50
C5677 CCSRCH561J50
C5624, C5631, C5649-C5651, C5678 CEHVKW470M16
C5616-C5618, C5636, C5638 CKSQYB105K16
C5652-C5657, C5681 CKSRYB103K50
C5619-C5623, C5626-C5628, C5630 CKSRYB104K25
C5632, C5634, C5644, C5671 CKSRYB104K25
C5679, C5680 CKSRYB104K25
C5640 CKSRYB473K50
C5635, C5637, C5642 CKSRYF474Z25
RESISTORS
R5672 RS1/10SR2700F
R5673 RS1/10SR3000F
Other Resistors RS1/10S###J
MAIN BLOCK5
SEMICONDUCTORS
IC5903 BA7078BF
IC5901 BA7657F
IC5905 SM5301CS
IC5904 TC74LCX157FTS1
IC5902 TC74VHC153FT
Q5901, Q5903 2SA1576A
Q5902, Q5904, Q5905 2SC4081
D5901-D5903 DAN217U
Mark No. Description Part No.
COILS AND FILTERS
L5905 CHIP COIL BTH1100
L5901-L5903 CHIP COIL BTH1102
L5904, L5907 CHIP COIL BTH1104
CAPACITORS
C5925, C5942 (2.2/16) ACG1133
C5934, C5945 (4.7/16) ACG1134
C5930 (100/16) ACH1430
C5901-C5903 (47/6.3) ACH1444
C5961 CCSRCH101J50
C5927 CCSRCH471J50
C5913-C5918 CCSRCH4R0C50
C5938 CCSRCH561J50
C5907-C5909, C5939, C5941, C5970 CEHVKW470M16
C5935-C5937, C5956, C5958 CKSQYB105K16
C5904-C5906, C5910-C5912 CKSRYB103K50
C5926, C5928, C5929, C5940 CKSRYB104K25
C5946-C5949, C5954, C5962, C5964 CKSRYB104K25
C5966-C5968 CKSRYB104K25
C5952 CKSRYB473K50
C5955, C5957, C5960 CKSRYF474Z25
RESISTORS
R5930 RS1/10SR2700F
R5931 RS1/10SR3000F
Other Resistors RS1/10S###J
MAIN BLOCK6
SEMICONDUCTORS
IC6302, IC6304 IDT2305A
IC6301 PD6435A
COILS AND FILTERS
F6301, F6302, F6304 CHIP BEEDS FILTER BTX1041
CAPACITORS
C6320 CEHVKW470M6R3
C6321-C6337 CKSRYB103K50
C6301-C6313, C6315, C6316, C6338 CKSRYB104K25
C6340, C6343 CKSRYB104K25
RESISTORS
R6356, R6364 RAB4CQ102J
R6301-R6312 RAB4CQ103J
R6313-R6324 RAB4CQ220J
R6334-R6345 RAB4CQ470J
Other Resistors RS1/10S###J
OTHERS
>
FU6301 PROTECTOR(4.5A) AEK1082
CN6301, CN6302 50P CONNECTER AKM1345
>
X6301 (14.3MHz) CERAMIC ASS1169
MAIN BLOCK7
SEMICONDUCTORS
>
IC6502 NJM2846DL3-33
IC6503 SN74LVC1G125DCK
IC6501 TDA8754HL/14/C1
Q6501-Q6503 2SA1576A
D6501 DAN202U
COILS AND FILTERS
L6501 INDUCTOR ATH1127
Mark No. Description Part No.
