Pioneer PDP-425CMX - Page 59

PDP-425CMX
59
5678
56
7
8
C
D
F
A
B
E
L6502 CHIP INDUCTOR ATL1148
F6501-F6505 CHIP BEEDS FILTER BTX1041
CAPACITORS
C6504 (2.2/16) ACG1133
C6511 (100/16) ACH1430
C6519, C6521 CCSRCH331J50
C6516 CCSRCH681J50
C6501, C6503 CEHVKW221M10
C6505, C6507, C6509, C6517, C6518 CKSQYB105K16
C6523, C6524, C6529, C6530 CKSQYB105K16
C6534, C6535 CKSQYB105K16
C6502, C6506, C6508, C6510 CKSRYB104K25
C6512-C6514, C6520, C6522 CKSRYB104K25
C6525, C6526, C6528, C6531, C6533 CKSRYB104K25
C6536, C6538-C6550, C6552, C6553 CKSRYB104K25
C6515 CKSRYB224K16
C6527, C6532, C6537 CKSRYB472K50
RESISTORS
R6512, R6515, R6518 RS1/10SR18R0F
R6510, R6513, R6516 RS1/10SR4300F
R6501-R6503 RS1/8SQ0R0J
Other Resistors RS1/10S###J
MAIN BLOCK8
SEMICONDUCTORS
>
IC6702 NJM2846DL3-33
IC6703 SN74LVC1G125DCK
IC6701 TDA8754HL/14/C1
Q6701-Q6703 2SA1576A
D6701 DAN202U
COILS AND FILTERS
L6701 INDUCTOR ATH1127
L6702 CHIP INDUCTOR ATL1148
F6701-F6705 CHIP BEEDS FILTER BTX1041
CAPACITORS
C6704 (2.2/16) ACG1133
C6711 (100/16) ACH1430
C6719, C6721 CCSRCH331J50
C6716 CCSRCH681J50
C6702, C6703 CEHVKW221M10
C6705, C6707, C6709, C6717, C6718 CKSQYB105K16
C6723, C6724, C6729, C6730 CKSQYB105K16
C6734, C6735 CKSQYB105K16
C6701, C6706, C6708, C6710 CKSRYB104K25
C6712-C6714, C6720, C6722 CKSRYB104K25
C6725, C6726, C6728, C6731, C6733 CKSRYB104K25
C6736, C6738-C6750, C6752, C6753 CKSRYB104K25
C6715 CKSRYB224K16
C6727, C6732, C6737 CKSRYB472K50
RESISTORS
R6712, R6715, R6718 RS1/10SR18R0F
R6710, R6713, R6716 RS1/10SR4300F
R6701-R6703 RS1/8SQ0R0J
Other Resistors RS1/10S###J
MAIN BLOCK9
SEMICONDUCTORS
IC7002, IC7005 BR24L02FJ-W
>
IC7003, IC7006 PQ20WZ11
Mark No. Description Part No.
IC7001 SII1169CTU
IC7004 SN74AHC2G66HDCT
Q7005 2SC2412K
Q7001, Q7002, Q7004 DTC144EUA
Q7003 SM6K2
D7001, D7010-D7012 DAN217U
D7002-D7009 MA147
COILS AND FILTERS
F7004 CHIP BEEDS FILTER BTX1041
F7002, F7003, F7005-F7010 DTL1041
CAPACITORS
C7002, C7004-C7006, C7032 (100/16) ACH1430
C7009, C7011, C7013, C7015 CCSRCH101J50
C7016 CCSRCH331J50
C7018, C7020 CEHVKW220M16
C7001, C7031 CKSQYB334K50
C7019 CKSRYB103K50
C7003, C7007, C7008, C7010, C7012 CKSRYB104K25
C7014, C7017, C7021-C7028, C7033 CKSRYB104K25
RESISTORS
R7042-R7053 RAB4CQ470J
R7008 RS1/10SR1801F
R7011, R7025 RS1/10SR2001F
R7012 RS1/10SR3900F
R7024 RS1/10SR5100F
R7039, R7054 RS1/8SQ0R0J
Other Resistors RS1/10S###J
OTHERS
CN7001 DVI CONNECTOR AKP1282
MAIN BLOCK10
SEMICONDUCTORS
IC8001 PE5525A
>
IC8003 PQ1MX55M2SPQ
>
IC8002 SI-3011ZD
D8001, D8002 DAN202U
COILS AND FILTERS
L8001-L8004 CHIP COIL BTH1104
F8001-F8003 CHIP BEEDS FILTER BTX1041
F8004, F8005 CHIP SOLID INDUCTOR DTL1041
CAPACITORS
C8006 (2.2/16) ACG1133
C8003, C8007, C8022 (100/16) ACH1430
C8001 CEHVKW470M16
C8038, C8041, C8044, C8056 CEHVKW470M6R3
C8047, C8049 CKSRYB103K50
C8002, C8004, C8008-C8021 CKSRYF104Z50
C8023-C8037, C8039, C8040 CKSRYF104Z50
C8042, C8043, C8045, C8046, C8048 CKSRYF104Z50
C8050, C8051, C8055, C8057 CKSRYF104Z50
RESISTORS
R8045-R8051 RAB4CQ101J
R8004 RS1/10SR1002F
R8044 RS1/10SR1302F
R8043 RS1/10SR3001F
R8003 RS1/10SR3901F
R8006-R8008, R8033 RS1/8SQ1R0J
Mark No. Description Part No.
