Pioneer PDP-4270XA Service Manual

PDP-427XD
166
1234
1234
C
D
F
A
B
E
10.4 LED INFORMATION
State
AC OFF or
Main power switch OFF
Standby power
management
Power ON
Power-down
Once OnceTwice n times500 msec 2.5 sec
Once OnceTwice n times500 msec
200 msec
200 msec
100 msec
100 msec
2.5 sec
Shutdown
No digital adjustment data
copied for backup
In the process of rewriting
the program of the
microcomputer
PDP-4270XD and
PDP-427XD only
RS-232C <=> SR+ switch
During reservation
video recordings
(Unit: Standby)
During factory operation
During sleep timer operation (∗2)
During reservation video
recordings (Unit: ON) ∗1
Blue
Red
Orange
Blue
Red
Orange
Blue
Red
Orange
Blue
Red
Orange
Blue
Red
Orange
Blue
Red
Orange
Blue
Red
Orange
Blue
Red
Orange
Blue
Red
Orange
Blue
Red
Orange
LED Pattern
POWER ON STANDBY REC TIMER
∗1: PDP-4270XD and PDP-427XD types
∗2: PDP-4270XA and PDP-427XA types
LED Pattern

Pioneer PDP-4270XA Specifications

General

3D	No
Depth	115 mm
Width	1040 mm
Height	679 mm
Weight	31500 g
Tuner type	Analog
Pixel pitch	- mm
Product color	Black, Silver
Noise reduction	Yes
RMS rated power	26 W
AC input voltage	220 - 240 V
Display diagonal	42 \
Channels quantity	99 channels
AC input frequency	50 - 60 Hz
Display brightness	1100 cd/m²
Display resolution	1024 x 768 pixels
Display technology	Plasma
Number of speakers	2
Teletext standards	Top-text
SCART ports quantity	3
USB 2.0 ports quantity	0
Annual energy consumption	- kWh
Display diagonal (metric)	106 cm
Analog signal format system	NTSC, NTSC 3.58, NTSC 4.43, PAL, PAL 60, PAL BG, PAL DK, PAL I, SECAM, SECAM B/G, SECAM D/K, SECAM L
Power consumption (standby)	0.3 W
Power consumption (typical)	287 W
Digital signal format system	-
Sound enhancement technology	FOCUS, SRS, TruBass
On Screen Display (OSD) languages	CZE, DAN, DEU, DUT, ENG, ESP, FIN, FRE, GRE, ITA, NOR, POL, POR, RUS, SWE
