Checkpoints
PH2401F
Cause/Countermeasure: No Diode
characteristic ]Exchange High Voltage
Board.
PH2401F
Symptom:No Picture. (Priming doesn’t flash if W-X
erminals are short-circuited.)
High Voltage Board; Surface
High Voltage Board; Reverse
K (57~59)
L (61~64)
M (66~69)
N (71~74)
O (76~78)
P (81~84)
Q (86~89)
R (91)
S (93~96)
T (99~103)
V (107)
W(109)
X (112)
J (55~56)
D (15~18)
F (33~35)
C (10~13)
A (1~4)
B (6~9)
E (24)
G (39~40)
H (49~50)
I (53)
OK: Diode characteristic
NG: Other than above
A-D M-L
A-E N-P
B-D O-P
C-D Q-R
E-R R-S
F-N R-T
G-M S-T
H-I T-V
I-J W-X
K-L
90
