Put on connectors and cables of good Board.
(Caution) Be sure to put on Heat Sink after assembling Data Relay Board.
Digital Board
7 connectors
Common Relay Board
1 connector
High Voltage
Board
6 connectors
Data Relay Board (LU)
8 connectors
Data Relay Board (RU)
9 connectors
Data Relay Board (LD)
8 connectors
Data Relay Board (RD)
9 connectors
Scan Relay Board (D)
5 connectors
Scan Relay Board (U)
5 connectors
Common Connection Board
5 connectors
98
