Pioneer 42" & 61" Plasma parts & board assy interchageability list
A
pplicable models: PDP4214HD, PDP42A3HD, PRO1410HD, PDP614MX, PDP6100HD, PDP424MV
Part description Latest Part # Old part #
PDP4214HD
PDP42A3HD
PDP6100HD
PRO1410HD
PDP614MX PDP424MV
Remarks
PDP Module 9S900116 9S900077, 3S361002 X X X
9S900064 3S342013 X
PDP-NP42H5MF01PA X X
Power Unit 3S110165 3S110164, 161 X X X
3S110211 X
Power SMPS 01403-0120 X X
Digital video ass
y
9S899731 (05D-27) X X X
9S899791 (05C-27) X X X See service manual pg 12-6 for
9S899792 (05C-28) X X X additional replacement target
9S899793 (05D-28) X X X versions.
9S899878 (03K-06) 9S899847 (03J-06) X
Digital Board 9S890002 (17C-08) X X
Digital Assy (Ucom& Video
)
010-2741 X X
DTT Analog Ass
y
010-2640 X X
Main PWB Ass
y
937J8M03 937J8M01 X
937J9M03 937J9M01 and M02 X
937P9M01 X
937M2M03 937M2M02 X
High Voltage Board 9S899891 (Ver 03B) X X
9S899523 X
Common Connection Board 9S899919 (Ver 02A) X X
Common PKG 9S899669 X X X
9S899869 9S899282 X
Y
Scanning PKG 9S899659 (Ver 02A) 9S899790 X X X
Scan Relay Board (Up) 9S899897 (Ver 02A) X X
9S899862 (Ver 02C) X X Up and down board versions
Scan Relay Board (Down) 9S899898 (Ver 02A) X X must match.
9S899863 (Ver 02C) X X
Scanning relay PKG(Lower) 9S899850 9S899661 X X X
9S899855 (Ver 02A) 9S899355 (Ver 01C) X Upper and lower board versions
9S899866 (Ver 02B) 9S899531 (Ver 01D) X must match.
Scanning relay PKG(Upper) 9S899849 9S899660 X X X
9S899854 (Ver 02A) 9S899351 (Ver 01C) X Upper and lower board versions
9S899865 (Ver 02B) 9S899528 (Ver 01D) X must match.
POWER SUPPLY
PLASMA PANEL ASSY
VIDEO PROCESSING ASSY
PANEL DIGITAL ASSY
9S899843 (05C-33)
9S899844 (05C-34)
X,YXSCAN MODULES
10
